T.R.O.L.L.

T.R.O.L.L.

Running Line Tensiometer - Overload Limiter

T.R.O.L.L. is the running line tensiometer, with overload limiter function, designed and "produced in Europe".

marked.

Ideal for use on winches, both new and already in operation, because the simple steps of installation does not require the interruption of the rope.

As the nordic giant from which it takes its name, T.R.O.L.L. is strong, sturdy, specially designed to work in the most extreme environments. The compact and careful design and its high reliability make this an incomparable tool for tension control and the safety of the rope pulling installations .

The standard models of T.R.O.L.L. cover a capacity range between 0 and 500 tons with ropes of diameter up to 120 mm.

The structure of T.R.O.L.L. is powder coated steel and all sliding parts are made of hardened steel and / or stainless steel. The tension of the rope is measured through a stainless steel pin load cell with high elastic properties.

CAPACITY from 0 to 500.000 kg

(different on request)

marked

Marked ATEX on request

IP67

stainless steel load cell

high mechanical resistance

Easy installation and operation

Interfaced with a wide range of electronic marked

Model	Weight	Max Load	Max Rope Ø	Dimensions
TROLL -5K	7 kg	5.000 daN	20 mm	28 x 18 x 18(h) cm
TROLL –25K	15 kg	25.000 daN	35 mm	28 x 18 x 18(h) cm
TROLL –50K	50 kg	50.000 daN	50 mm	48 x 25 x 38(h) cm
TROLL –150K	120 kg	150.000 daN	60 mm	72 x 33 x 56(h) cm
TROLL –350K	200 kg	350.000 daN	85 mm	91 x 39 x 67(h) cm
TROLL –500K	350 kg	500.000 daN	120 mm	105 x 42 x 78(h) cm

Note: The measures reported in the table are indicative and subject to change by the manufacturer.

SPECIFICATIONS

(Pin Load Cell)

SAFE OVERLOAD	150 % F.S.
BREAKING OVERLOAD	300 % F.S.
SUPPLY VOLTAGE	15 Vcc MAX
OUTPUT	1 mV/V
OUTPUT TOLLERANCE	0,1 % F.S.
ZERO TOLLERANCE	1 % F.S.
LINEARITY	0,2 % F.S.
HYSTERESIS	0,2 % F.S.
REAPEATABILITY	0,2 % F.S.
INPUT RESISTANCE	350 – 360 Ohm
OUTPUT RESISTANCE	350 – 351 Ohm
INSULATION RESISTANCE	MIN 2000 MOhm
CREEP	0,2 % F.S.
TEMPERATURE RANGE	-10 / +40 °C
MAX TEMPERATURE RANGE	-20 / +70 °C
TEMPERATURE EFFECT ZERO	0,003 % F.S. /°C
TEMPERATURE EFFECT OUTPUT	0,002 % F.S. /°C
ELECTRIC WIRE (STANDARD) 4x0,25	5 METERS
RED: SUPPLY +	BLACK: SUPPLY –
GREEN: OUTPUT SIGNAL +	WHITE: OUTPUT SIGNAL –

MECHANICAL SPECIFICATIONS

Structure

Ø powder coated steel

Ø (Optional) stainless steel

Fasteners

Ø stainless steel AISI 316

Pin Load cell & pins

Ø 17.4PH

Ø stainles steel

Pulleys

Ø Hardened steel (standard)

Ø 17.4 PH (optional)

Bearings

Ø Self lubricating

Working Temperature

Ø from -20° to +70°C

Output Signal

Ø 1 mV/V (standard)

Ø analogic 4-20 mA or 0-10V (optional)

Ø double bridge for redundant safety (optional)
